Your structured data into Tensorflow.¶

ML training often expects flat data, like a line in a CSV. tf.Example was designed to represent flat data. But the data you care about and want to predict things about usually starts out structured.

Over and over again you have to write transform code that turns your structured data into Tensors. This repetitive transform code must be rewritten over and over for all your ML pipelines both for training and serving! And it lets bugs slip into your ML pipeline.

struct2tensor lets you take advantage of structured data within your ML pipelines. It is:

for: ML Engineers
who: train models on data that starts out structured
it is: a python library
that: transforms your structured data into model-friendly (Sparse, Raggged, Dense, ...) tensors hermetically within your model
unlike: writing custom transforms over and over for training and serving.

struct2tensor diagram showing the transform happens in the model

Demo example¶

Suppose we have this structured data we want to train on. The source example data format is a protobuff. struct2tensor was built internally and works on protobuffers now. It can be extended to parquet, json, etc. in the future.

# e.g. a web session
message Session{
  message SessionInfo {
    string session_feature = 1;
    double session_duration_sec = 2;
  }
  SessionInfo session_info = 1;
  message Event {
    string query = 1;
    message Action {
      int number_of_views = 1;
    }
    repeated Action action = 2;
  }
  repeated Event event = 2;
}

In 3 steps we'll extract the fields we want with struct2tensor. We'll end up with batch-aligned SparseTensors:

Tell our model what examples we care about, e.g. event (submessage Session::Event).
Pick the proto fields that we think are good features, say:

session_info.session_feature
event.query

Identify the label to predict, say event.action.number_of_views (the actual label could be sum(action.number_of_views for action in event))

Then we can build a struct2tensor query that:

parses instances of this protocol buffer
transforms the fields we care about
creates the necessary SparseTensors

Don't worry about some of these terms yet. We'll show you an example. And then explain the terms later.

Install required packages (internal colab users: skip)¶

In [ ]:

Copied!





#@test {"skip": true}
# install struct2tensor
!pip install struct2tensor
# graphviz for pretty output
!pip install graphviz
#@test {"skip": true}
# install struct2tensor
!pip install struct2tensor
# graphviz for pretty output
!pip install graphviz

Requirement already satisfied: struct2tensor in /usr/local/lib/python3.6/dist-packages (0.0.1.dev6)
Requirement already satisfied: tensorflow-metadata>=0.13.0 in /usr/local/lib/python3.6/dist-packages (from struct2tensor) (0.15.1)
Requirement already satisfied: protobuf>=3.8.0 in /usr/local/lib/python3.6/dist-packages (from struct2tensor) (3.10.0)
Requirement already satisfied: tensorflow==1.15.0 in /usr/local/lib/python3.6/dist-packages (from struct2tensor) (1.15.0)
Requirement already satisfied: googleapis-common-protos in /usr/local/lib/python3.6/dist-packages (from tensorflow-metadata>=0.13.0->struct2tensor) (1.6.0)
Requirement already satisfied: six>=1.9 in /usr/local/lib/python3.6/dist-packages (from protobuf>=3.8.0->struct2tensor) (1.12.0)
Requirement already satisfied: setuptools in /usr/local/lib/python3.6/dist-packages (from protobuf>=3.8.0->struct2tensor) (42.0.1)
Requirement already satisfied: numpy<2.0,>=1.16.0 in /usr/local/lib/python3.6/dist-packages (from tensorflow==1.15.0->struct2tensor) (1.17.4)
Requirement already satisfied: opt-einsum>=2.3.2 in /usr/local/lib/python3.6/dist-packages (from tensorflow==1.15.0->struct2tensor) (3.1.0)
Requirement already satisfied: keras-preprocessing>=1.0.5 in /usr/local/lib/python3.6/dist-packages (from tensorflow==1.15.0->struct2tensor) (1.1.0)
Requirement already satisfied: termcolor>=1.1.0 in /usr/local/lib/python3.6/dist-packages (from tensorflow==1.15.0->struct2tensor) (1.1.0)
Requirement already satisfied: wheel>=0.26 in /usr/local/lib/python3.6/dist-packages (from tensorflow==1.15.0->struct2tensor) (0.33.6)
Requirement already satisfied: grpcio>=1.8.6 in /usr/local/lib/python3.6/dist-packages (from tensorflow==1.15.0->struct2tensor) (1.15.0)
Requirement already satisfied: tensorboard<1.16.0,>=1.15.0 in /usr/local/lib/python3.6/dist-packages (from tensorflow==1.15.0->struct2tensor) (1.15.0)
Requirement already satisfied: keras-applications>=1.0.8 in /usr/local/lib/python3.6/dist-packages (from tensorflow==1.15.0->struct2tensor) (1.0.8)
Requirement already satisfied: tensorflow-estimator==1.15.1 in /usr/local/lib/python3.6/dist-packages (from tensorflow==1.15.0->struct2tensor) (1.15.1)
Requirement already satisfied: google-pasta>=0.1.6 in /usr/local/lib/python3.6/dist-packages (from tensorflow==1.15.0->struct2tensor) (0.1.8)
Requirement already satisfied: gast==0.2.2 in /usr/local/lib/python3.6/dist-packages (from tensorflow==1.15.0->struct2tensor) (0.2.2)
Requirement already satisfied: wrapt>=1.11.1 in /usr/local/lib/python3.6/dist-packages (from tensorflow==1.15.0->struct2tensor) (1.11.2)
Requirement already satisfied: absl-py>=0.7.0 in /usr/local/lib/python3.6/dist-packages (from tensorflow==1.15.0->struct2tensor) (0.8.1)
Requirement already satisfied: astor>=0.6.0 in /usr/local/lib/python3.6/dist-packages (from tensorflow==1.15.0->struct2tensor) (0.8.0)
Requirement already satisfied: werkzeug>=0.11.15 in /usr/local/lib/python3.6/dist-packages (from tensorboard<1.16.0,>=1.15.0->tensorflow==1.15.0->struct2tensor) (0.16.0)
Requirement already satisfied: markdown>=2.6.8 in /usr/local/lib/python3.6/dist-packages (from tensorboard<1.16.0,>=1.15.0->tensorflow==1.15.0->struct2tensor) (3.1.1)
Requirement already satisfied: h5py in /usr/local/lib/python3.6/dist-packages (from keras-applications>=1.0.8->tensorflow==1.15.0->struct2tensor) (2.8.0)
Requirement already satisfied: graphviz in /usr/local/lib/python3.6/dist-packages (0.10.1)

Some Pretty Printing and Imports¶

(not the "real" work yet)

In [ ]:

Copied!





import base64
import numpy as np
import pprint
import os
import tensorflow
from graphviz import Source

import tensorflow as tf

from IPython.display import Image
from IPython.lib import pretty

import struct2tensor as s2t
from struct2tensor.test import test_pb2
from google.protobuf import text_format


def _display(graph):
  """Renders a graphviz digraph."""
  s = Source(graph)
  s.format='svg'
  return s


def _create_query_from_text_sessions(text_sessions):
  """Creates a struct2tensor query from a list of pbtxt of struct2tensor.test.Session."""
  sessions = tf.constant([
      text_format.Merge(
          text_session,
          test_pb2.Session()
      ).SerializeToString()
      for text_session in text_sessions
  ])
  return s2t.create_expression_from_proto(
    sessions, test_pb2.Session.DESCRIPTOR)

def _prensor_pretty_printer(prensor, p, cycle):
  """Pretty printing function for struct2tensor.prensor.Prensor"""
  pretty.pprint(prensor.get_sparse_tensors())

def _sp_pretty_printer(sp, p, cycle):
  """Pretty printing function for SparseTensor."""

  del cycle
  p.begin_group(4, "SparseTensor(")
  p.text("values={}, ".format(sp.values.numpy().tolist()))
  p.text("dense_shape={}, ".format(sp.dense_shape.numpy().tolist()))
  p.break_()
  p.text("indices={}".format(sp.indices.numpy().tolist()))
  p.end_group(4, ")")


pretty.for_type(tf.SparseTensor, _sp_pretty_printer)
pretty.for_type(s2t.Prensor, _prensor_pretty_printer)

_pretty_print = pretty.pprint

print("type-specific pretty printing ready to go")
import base64
import numpy as np
import pprint
import os
import tensorflow
from graphviz import Source

import tensorflow as tf

from IPython.display import Image
from IPython.lib import pretty

import struct2tensor as s2t
from struct2tensor.test import test_pb2
from google.protobuf import text_format


def _display(graph):
  """Renders a graphviz digraph."""
  s = Source(graph)
  s.format='svg'
  return s


def _create_query_from_text_sessions(text_sessions):
  """Creates a struct2tensor query from a list of pbtxt of struct2tensor.test.Session."""
  sessions = tf.constant([
      text_format.Merge(
          text_session,
          test_pb2.Session()
      ).SerializeToString()
      for text_session in text_sessions
  ])
  return s2t.create_expression_from_proto(
    sessions, test_pb2.Session.DESCRIPTOR)

def _prensor_pretty_printer(prensor, p, cycle):
  """Pretty printing function for struct2tensor.prensor.Prensor"""
  pretty.pprint(prensor.get_sparse_tensors())

def _sp_pretty_printer(sp, p, cycle):
  """Pretty printing function for SparseTensor."""

  del cycle
  p.begin_group(4, "SparseTensor(")
  p.text("values={}, ".format(sp.values.numpy().tolist()))
  p.text("dense_shape={}, ".format(sp.dense_shape.numpy().tolist()))
  p.break_()
  p.text("indices={}".format(sp.indices.numpy().tolist()))
  p.end_group(4, ")")


pretty.for_type(tf.SparseTensor, _sp_pretty_printer)
pretty.for_type(s2t.Prensor, _prensor_pretty_printer)

_pretty_print = pretty.pprint

print("type-specific pretty printing ready to go")

type-specific pretty printing ready to go

The real work:¶

A function that parses our structured data (protobuffers) into tensors:

In [ ]:

Copied!





@tf.function(input_signature=[tf.TensorSpec(shape=(None), dtype=tf.string)], autograph=False)
def parse_session(serialized_sessions):
  """A TF function parsing a batch of serialized Session protos into tensors.

  It is a TF graph that takes one 1-D tensor as input, and outputs a
  Dict[str, tf.SparseTensor]
  """
  query = s2t.create_expression_from_proto(
      serialized_sessions, test_pb2.Session.DESCRIPTOR)
  # Move all the fields of our interest to under "event".
  query = query.promote_and_broadcast({
          "session_feature": "session_info.session_feature",
          "action_number_of_views": "event.action.number_of_views" },
          "event")
  # Specify "event" to be examples.
  query = query.reroot("event")
  # Extract all the fields of our interest.
  projection = query.project(["session_feature", "query", "action_number_of_views"])
  prensors = s2t.calculate_prensors([projection])

  output_sparse_tensors = {}
  for prensor in prensors:
    path_to_tensor = prensor.get_sparse_tensors()
    output_sparse_tensors.update({str(k): v for k, v in path_to_tensor.items()})

  return output_sparse_tensors

print("Defined the workhorse func: (structured data at rest) -> (tensors)")
@tf.function(input_signature=[tf.TensorSpec(shape=(None), dtype=tf.string)], autograph=False)
def parse_session(serialized_sessions):
  """A TF function parsing a batch of serialized Session protos into tensors.

  It is a TF graph that takes one 1-D tensor as input, and outputs a
  Dict[str, tf.SparseTensor]
  """
  query = s2t.create_expression_from_proto(
      serialized_sessions, test_pb2.Session.DESCRIPTOR)
  # Move all the fields of our interest to under "event".
  query = query.promote_and_broadcast({
          "session_feature": "session_info.session_feature",
          "action_number_of_views": "event.action.number_of_views" },
          "event")
  # Specify "event" to be examples.
  query = query.reroot("event")
  # Extract all the fields of our interest.
  projection = query.project(["session_feature", "query", "action_number_of_views"])
  prensors = s2t.calculate_prensors([projection])

  output_sparse_tensors = {}
  for prensor in prensors:
    path_to_tensor = prensor.get_sparse_tensors()
    output_sparse_tensors.update({str(k): v for k, v in path_to_tensor.items()})

  return output_sparse_tensors

print("Defined the workhorse func: (structured data at rest) -> (tensors)")

Defined the workhorse func: (structured data at rest) -> (tensors)

Lets see it in action:¶

In [ ]:

Copied!





serialized_sessions = tf.constant([
    text_format.Merge(
        """
        session_info {
          session_duration_sec: 1.0
          session_feature: "foo"
        }
        event {
          query: "Hello"
          action {
            number_of_views: 1
          }
          action {
          }
        }
        event {
          query: "world"
          action {
            number_of_views: 2
          }
          action {
            number_of_views: 3
          }
        }
        """,
        test_pb2.Session()
    ).SerializeToString()
])

_pretty_print(parse_session(serialized_sessions))
serialized_sessions = tf.constant([
    text_format.Merge(
        """
        session_info {
          session_duration_sec: 1.0
          session_feature: "foo"
        }
        event {
          query: "Hello"
          action {
            number_of_views: 1
          }
          action {
          }
        }
        event {
          query: "world"
          action {
            number_of_views: 2
          }
          action {
            number_of_views: 3
          }
        }
        """,
        test_pb2.Session()
    ).SerializeToString()
])

_pretty_print(parse_session(serialized_sessions))

{'action_number_of_views': SparseTensor(values=[1, 2, 3], dense_shape=[2, 2],
     indices=[[0, 0], [1, 0], [1, 1]]),
 'query': SparseTensor(values=[b'Hello', b'world'], dense_shape=[2],
     indices=[[0], [1]]),
 'session_feature': SparseTensor(values=[b'foo', b'foo'], dense_shape=[2, 1],
     indices=[[0, 0], [1, 0]])}

See how we went from our pre-pipeline data (the Protobuffer) all the way to the structured data, packed into SparseTensors?

Digging Far Deeper¶

Interested and want to learn more? Read on...

Let's define several terms we mentioned before:

Prensor¶

A Prensor (protobuffer + tensor) is a data structure storing the data we work on. We use protobuffers a lot at Google. struct2tensor can support other structured formats, too.

For example, throughout this colab we will be using proto struct2tensor.test.Session. A schematic visualization of a selected part of the prensor from that proto looks like:

In [ ]:

Copied!





#@title { display-mode: "form" }
#@test {"skip": true}

_display("""
digraph {
  root -> session [label="*"];
  session -> event [label="*"];
  session -> session_id [label="?"];
  event -> action [label="*"];
  event -> query_token [label="*"]
  action -> number_of_views [label="?"];
}
""")
#@title { display-mode: "form" }
#@test {"skip": true}

_display("""
digraph {
  root -> session [label="*"];
  session -> event [label="*"];
  session -> session_id [label="?"];
  event -> action [label="*"];
  event -> query_token [label="*"]
  action -> number_of_views [label="?"];
}
""")

Out[ ]:

No description has been provided for this image

We will be using visualizations like this to demostrate struct2tensor queries later.

Note:

The "*" on the edge means the pointed node has repeated values; while the "?" means it has an optional value.
There is always a "root" node whose only child is the root of the structure. Note that it's "repeated" because one struct2tensorTree can represent multiple instances of a structure.

struct2tensor Query¶

A struct2tensor query transforms a Prensor into another Prensor.

For example, broadcast is a query that replicates a node as a child of one of its siblings.

Applying

broadcast(
    source_path="session.session_id",
    sibling="event",
    new_field_name="session_session_id")

on the previous tree gives:

In [ ]:

Copied!





#@title { display-mode: "form" }
#@test {"skip": true}

_display("""
digraph {
  session_session_id [color="red"];
  root -> session [label="*"];
  session -> event [label="*"];
  session -> session_id [label="?"];
  event -> action [label="*"];
  event -> session_session_id [label="?"];
  event -> query_token [label="*"];
  action -> number_of_views [label="?"];
}
""")
#@title { display-mode: "form" }
#@test {"skip": true}

_display("""
digraph {
  session_session_id [color="red"];
  root -> session [label="*"];
  session -> event [label="*"];
  session -> session_id [label="?"];
  event -> action [label="*"];
  event -> session_session_id [label="?"];
  event -> query_token [label="*"];
  action -> number_of_views [label="?"];
}
""")

Out[ ]:

We will talk about common struct2tensor queries in later sections.

Projection¶

A projection of paths in a Prensor produces another Prensor with just the selected paths.

Logical representation of a projection¶

The structure of the projected path can be represented losslessly as nested lists. For example, the projection of event.action.number_of_views from the struct2tensorTree formed by the following two instances of struct2tensor.test.Session:

{
  event { action { number_of_views: 1} action { number_of_views: 2} action {} }
  event {}
}, {
  event { action { number_of_views: 3} }
}

is:

[  # the outer list has two elements b/c there are two Session protos.
 [  # the first proto has two events
   [[1],[2],[]],  # 3 actions, the last one does not have a number_of_views.
   [], # the second event does not have action
 ],
 [ # the second proto has one event
   [[3]],
 ],
]

Representing nested lists with `tf.SparseTensor`¶

struct2tensor uses tf.SparseTensor to represent the above nested list in the projection results. Note that tf.SparseTensor essentially enforces that the lists nested at the same level to have the same length (because the there is a certain size for each dimension), therefore this representation is lossy. The above nested lists, when written as a SparseTensor will look like:

tf.SparseTensor(
  dense_shape=[2, 2, 3, 1],  # each is the maximum length of lists at the same nesting level.
  values = [1, 2, 3],
  indices = [[0, 0, 0, 0], [0, 0, 1, 0], [1, 0, 0, 0]]
)

Note that the last dimension is useless: the index of that dimension will always be 0 for any present value because number_of_views is an optional field. So struct2tensors library will actually "squeeze" all the optional dimensions.

The actual result would be:

In [ ]:

Copied!





query = _create_query_from_text_sessions(['''
  event { action { number_of_views: 1} action { number_of_views: 2} action {} }
  event {}
  ''', '''
  event { action { number_of_views: 3} }
  ''']
  ).project(["event.action.number_of_views"])

prensor = s2t.calculate_prensors([query])
pretty.pprint(prensor)
query = _create_query_from_text_sessions(['''
  event { action { number_of_views: 1} action { number_of_views: 2} action {} }
  event {}
  ''', '''
  event { action { number_of_views: 3} }
  ''']
  ).project(["event.action.number_of_views"])

prensor = s2t.calculate_prensors([query])
pretty.pprint(prensor)

[{event.action.number_of_views: SparseTensor(values=[1, 2, 3], dense_shape=[2, 2, 3],
     indices=[[0, 0, 0], [0, 0, 1], [1, 0, 0]])}
]

struct2tensor's internal data model is closer to the above "nested lists" abstraction and sometimes it's easier to reason with "nested lists" than with SparseTensors.

Recently, tf.RaggedTensor was introduced to represent nested lists exactly. We are working on adding support for projecting into ragged tensors.

Common struct2tensor Queries¶

`promote`¶

Promotes a node to become a sibling of its parent. If the node is repeated, then all its values are concatenated (the order is preserved).

In [ ]:

Copied!





#@title { display-mode: "form" }
#@test {"skip": true}

_display('''
digraph {
  root -> session [label="*"];
  session -> event [label="*"];
  event -> query_token [label="*"];
}
''')
#@title { display-mode: "form" }
#@test {"skip": true}

_display('''
digraph {
  root -> session [label="*"];
  session -> event [label="*"];
  event -> query_token [label="*"];
}
''')

Out[ ]:

promote(source_path="event.query_token", new_field_name="event_query_token")

In [ ]:

Copied!





#@title { display-mode: "form" }
#@test {"skip": true}

_display('''
digraph {
  event_query_token [color="red"];
  root -> session [label="*"];
  session -> event [label="*"];
  session -> event_query_token [label="*"];
  event -> query_token [label="*"];
}
''')
#@title { display-mode: "form" }
#@test {"skip": true}

_display('''
digraph {
  event_query_token [color="red"];
  root -> session [label="*"];
  session -> event [label="*"];
  session -> event_query_token [label="*"];
  event -> query_token [label="*"];
}
''')

Out[ ]:

In [ ]:

Copied!





query = (_create_query_from_text_sessions([
"""
event {
  query_token: "abc"
  query_token: "def"
}
event {
  query_token: "ghi"
}
"""])
        .promote(source_path="event.query_token", new_field_name="event_query_token")
        .project(["event_query_token"]))

prensor = s2t.calculate_prensors([query])

_pretty_print(prensor)
query = (_create_query_from_text_sessions([
"""
event {
  query_token: "abc"
  query_token: "def"
}
event {
  query_token: "ghi"
}
"""])
        .promote(source_path="event.query_token", new_field_name="event_query_token")
        .project(["event_query_token"]))

prensor = s2t.calculate_prensors([query])

_pretty_print(prensor)

[{event_query_token: SparseTensor(values=[b'abc', b'def', b'ghi'], dense_shape=[1, 3],
     indices=[[0, 0], [0, 1], [0, 2]])}
]

The projected structure is like:

{
  # this is under Session.
  event_query_token: "abc"
  event_query_token: "def"
  event_query_token: "ghi"
}

`broadcast`¶

Broadcasts the value of a node to one of its sibling. The value will be replicated if the sibling is repeated. This is similar to TensorFlow and Numpy's broadcasting semantics.

In [ ]:

Copied!





#@title { display-mode: "form" }
#@test {"skip": true}

_display('''
digraph {
  root -> session [label="*"];
  session -> session_id [label="?"];
  session -> event [label="*"];
}
''')
#@title { display-mode: "form" }
#@test {"skip": true}

_display('''
digraph {
  root -> session [label="*"];
  session -> session_id [label="?"];
  session -> event [label="*"];
}
''')

Out[ ]:

broadcast(source_path="session_id", sibling_field="event", new_field_name="session_session_id")

In [ ]:

Copied!





#@title { display-mode: "form" }
#@test {"skip": true}

_display('''
digraph {
  session_session_id [color="red"];
  root -> session [label="*"];
  session -> session_id [label="?"];
  session -> event [label="*"];
  event -> session_session_id [label="?"];
}
''')
#@title { display-mode: "form" }
#@test {"skip": true}

_display('''
digraph {
  session_session_id [color="red"];
  root -> session [label="*"];
  session -> session_id [label="?"];
  session -> event [label="*"];
  event -> session_session_id [label="?"];
}
''')

Out[ ]:

In [ ]:

Copied!





query = (_create_query_from_text_sessions([
"""
session_id: 8
event { }
event { }
"""])
        .broadcast(source_path="session_id",
                   sibling_field="event",
                   new_field_name="session_session_id")
        .project(["event.session_session_id"]))

prensor = s2t.calculate_prensors([query])
_pretty_print(prensor)
query = (_create_query_from_text_sessions([
"""
session_id: 8
event { }
event { }
"""])
        .broadcast(source_path="session_id",
                   sibling_field="event",
                   new_field_name="session_session_id")
        .project(["event.session_session_id"]))

prensor = s2t.calculate_prensors([query])
_pretty_print(prensor)

[{event.session_session_id: SparseTensor(values=[8, 8], dense_shape=[1, 2],
     indices=[[0, 0], [0, 1]])}
]

The projected structure is like:

{
  event {
    session_session_id: 8
  }
  event {
    session_session_id: 8
  }
}

`promote_and_broadcast`¶

The query accepts multiple source fields and a destination field. For each source field, it first promotes it to the least common ancestor with the destination field (if necessary), then broadcasts it to the destination field (if necessary).

Usually for the purpose of machine learning, this gives a reasonable flattened representation of nested structures.

promote_and_broadcast(
    path_dictionary={
        'session_info_duration_sec': 'session_info.session_duration_sec'},
    dest_path_parent='event.action')

is equivalent to:

promote(source_path='session_info.session_duration_sec',
    new_field_name='anonymous_field1')

broadcast(source_path='anonymous_field1',
    sibling_field='event.action',
    new_field_name='session_info_duration_sec')

`map_field_values`¶

Creates a new node that is a sibling of a leaf node. The values of the new node are results of applying the given function to the values of the source node.

Note that the function provided takes 1-D tensor that contains all the values of the source node as input and should also output a 1-D tensor of the same size, and it should build TF ops.

In [ ]:

Copied!





query = (_create_query_from_text_sessions([
"""
session_id: 8
""",
"""
session_id: 9
"""])
        .map_field_values("session_id", lambda x: tf.add(x, 1), dtype=tf.int64,
                          new_field_name="session_id_plus_one")
        .project(["session_id_plus_one"]))

prensor = s2t.calculate_prensors([query])

_pretty_print(prensor)
query = (_create_query_from_text_sessions([
"""
session_id: 8
""",
"""
session_id: 9
"""])
        .map_field_values("session_id", lambda x: tf.add(x, 1), dtype=tf.int64,
                          new_field_name="session_id_plus_one")
        .project(["session_id_plus_one"]))

prensor = s2t.calculate_prensors([query])

_pretty_print(prensor)

[{session_id_plus_one: SparseTensor(values=[9, 10], dense_shape=[2],
     indices=[[0], [1]])}
]

`reroot`¶

Makes the given node the new root of the struct2tensorTree. This has two effects:

restricts the scope of the struct2tensorTree
- The field paths in all the following queries are relative to the new root
- There's no way to refer to nodes that are outside the subtree rooted at the new root.
changes the batch dimension.

In [ ]:

Copied!





#@title { display-mode: "form" }
#@test {"skip": true}

_display('''
digraph {
  root -> session [label="*"];
  session -> session_id [label="?"];
  session -> event [label="*"];
  event -> event_id [label="?"];
}
''')
#@title { display-mode: "form" }
#@test {"skip": true}

_display('''
digraph {
  root -> session [label="*"];
  session -> session_id [label="?"];
  session -> event [label="*"];
  event -> event_id [label="?"];
}
''')

Out[ ]:

reroot("event")

In [ ]:

Copied!





#@title { display-mode: "form" }
#@test {"skip": true}

_display('''
digraph {
  root -> event [label="*"];
  event -> event_id [label="?"];
}
''')
#@title { display-mode: "form" }
#@test {"skip": true}

_display('''
digraph {
  root -> event [label="*"];
  event -> event_id [label="?"];
}
''')

Out[ ]:

In [ ]:

Copied!





#@title { display-mode: "form" }
text_protos = ["""
session_id: 1
event {
  event_id: "a"
}
event {
  event_id: "b"
}
""",
"""
session_id: 2
""",
"""
session_id: 3
event {
  event_id: "c"
}
"""
]
print("""Assume the following Sessions: """)
print([text_format.Merge(p, s2t.test.test_pb2.Session()) for p in text_protos])
print("\n")
reroot_example_query = _create_query_from_text_sessions(text_protos)

print("""project(["event.event_id"]) before reroot() (the batch dimension is the index to sessions):""")
_pretty_print(s2t.calculate_prensors([reroot_example_query.project(["event.event_id"])]))
print("\n")
print("""project(["event_id"]) after reroot() (the batch dimension becomes the index to events):""")
_pretty_print(s2t.calculate_prensors([reroot_example_query.reroot("event").project(["event_id"])]))
#@title { display-mode: "form" }
text_protos = ["""
session_id: 1
event {
  event_id: "a"
}
event {
  event_id: "b"
}
""",
"""
session_id: 2
""",
"""
session_id: 3
event {
  event_id: "c"
}
"""
]
print("""Assume the following Sessions: """)
print([text_format.Merge(p, s2t.test.test_pb2.Session()) for p in text_protos])
print("\n")
reroot_example_query = _create_query_from_text_sessions(text_protos)

print("""project(["event.event_id"]) before reroot() (the batch dimension is the index to sessions):""")
_pretty_print(s2t.calculate_prensors([reroot_example_query.project(["event.event_id"])]))
print("\n")
print("""project(["event_id"]) after reroot() (the batch dimension becomes the index to events):""")
_pretty_print(s2t.calculate_prensors([reroot_example_query.reroot("event").project(["event_id"])]))

Assume the following Sessions:
[session_id: 1
event {
  event_id: "a"
}
event {
  event_id: "b"
}
, session_id: 2
, session_id: 3
event {
  event_id: "c"
}
]


project(["event.event_id"]) before reroot() (the batch dimension is the index to sessions):
[{event.event_id: SparseTensor(values=[b'a', b'b', b'c'], dense_shape=[3, 2],
     indices=[[0, 0], [0, 1], [2, 0]])}
]


project(["event_id"]) after reroot() (the batch dimension becomes the index to events):
[{event_id: SparseTensor(values=[b'a', b'b', b'c'], dense_shape=[3],
     indices=[[0], [1], [2]])}
]

Proto Map¶

You can specify a key for the proto map field in a path via brackets.

Given the following tf.Example:

features {
  feature {
    key: "my_feature"
    value {
      float_list {
        value: 1.0
      }
    }
  }
  feature {
    key: "other_feature"
    value {
      bytes_list {
        value: "my_val"
      }
    }
  }
}

To get the values of my_feature and other_feature, we can promote_and_broadcast and project the following paths: features.feature[my_feature].float_list.value and features.feature[other_feature].bytes_list.value

This results in the following dict of ragged tensors:

{
  features.my_new_feature: <tf.RaggedTensor [[[1.0]]]>,
  features.other_new_feature: <tf.RaggedTensor [[[b'my_val']]]>
}

Note: we renamed my_feature to my_new_feature in the promote_and_broadcast (and similarly for other_feature).

In [6]:

Copied!





tf_example = text_format.Parse("""
features {
  feature {
    key: "my_feature"
    value {
      float_list {
        value: 1.0
      }
    }
  }
  feature {
    key: "other_feature"
    value {
      bytes_list {
        value: "my_val"
      }
    }
  }
}
""", tf.train.Example())

query = s2t.create_expression_from_proto(
    tf_example.SerializeToString(), tf.train.Example.DESCRIPTOR)
query = query.promote_and_broadcast({'my_new_feature': "features.feature[my_feature].float_list.value", "other_new_feature": "features.feature[other_feature].bytes_list.value"}, "features")
query = query.project(["features.my_new_feature", "features.other_new_feature"])
[prensor] = s2t.calculate_prensors([query])
ragged_tensors = prensor.get_ragged_tensors()

print(ragged_tensors)
tf_example = text_format.Parse("""
features {
  feature {
    key: "my_feature"
    value {
      float_list {
        value: 1.0
      }
    }
  }
  feature {
    key: "other_feature"
    value {
      bytes_list {
        value: "my_val"
      }
    }
  }
}
""", tf.train.Example())

query = s2t.create_expression_from_proto(
    tf_example.SerializeToString(), tf.train.Example.DESCRIPTOR)
query = query.promote_and_broadcast({'my_new_feature': "features.feature[my_feature].float_list.value", "other_new_feature": "features.feature[other_feature].bytes_list.value"}, "features")
query = query.project(["features.my_new_feature", "features.other_new_feature"])
[prensor] = s2t.calculate_prensors([query])
ragged_tensors = prensor.get_ragged_tensors()

print(ragged_tensors)

{features.my_new_feature: <tf.RaggedTensor [[[1.0]]]>, features.other_new_feature: <tf.RaggedTensor [[[b'my_val']]]>}

Apache Parquet Support¶

struct2tensor offers an Apache Parquet tf.DataSet that allows reading from a Parquet file and apply queries to manipulate the structure of the data.

Because of the powerful struct2tensor library, the dataset will only read the Parquet columns that are required. This reduces I/O cost if we only need a select few columns.

Preparation¶

Please run the code cell at Some Pretty Printing and Imports to ensure that all required modules are imported, and that pretty print works properly.

Prepare the input data¶

In [ ]:

Copied!

# Download our sample data file from the struct2tensor repository. The desciption of the data is below.
#@test {"skip": true}

!curl -o dremel_example.parquet 'https://raw.githubusercontent.com/google/struct2tensor/master/struct2tensor/testdata/parquet_testdata/dremel_example.parquet'
# Download our sample data file from the struct2tensor repository. The desciption of the data is below.
#@test {"skip": true}

!curl -o dremel_example.parquet 'https://raw.githubusercontent.com/google/struct2tensor/master/struct2tensor/testdata/parquet_testdata/dremel_example.parquet'

  % Total    % Received % Xferd  Average Speed   Time    Time     Time  Current
                                 Dload  Upload   Total   Spent    Left  Speed
100  1657  100  1657    0     0   8122      0 --:--:-- --:--:-- --:--:--  8122

Example¶

We will use a sample Parquet data file (dremel_example.parquet), which contains data based on the example used in this paper: https://storage.googleapis.com/pub-tools-public-publication-data/pdf/36632.pdf

The file dremel_example.parquet has the following schema:

message Document {
  required int64 DocId;
  optional group Links {
    repeated int64 Backward;
    repeated int64 Forward; }
  repeated group Name {
    repeated group Language {
      required string Code;
      optional string Country; }
    optional string Url; }}

and contains the following data:

Document
  DocId: 10
  Links
    Forward: 20
    Forward: 40
    Forward: 60
  Name
    Language
      Code: 'en-us'
      Country: 'us'
    Language
      Code: 'en'
    Url: 'http://A'
  Name
    Url: 'http://B'
  Name
    Language
      Code: 'en-gb'
      Country: 'gb'
Document
  DocId: 20
  Links
    Backward: 10
    Backward: 30
    Forward: 80
  Name
    Url: 'http://C'

In this example, we will promote and broadcast the field Links.Forward and project it.

batch_size will be the number of records (Document) per prensor. This works with optional and repeated fields, and will be able to batch the entire record.

Feel free to try batch_size = 2 in the below code. (Note this parquet file only has 2 records (Document) total).

In [ ]:

Copied!





#@test {"skip": true}

from struct2tensor import expression_impl

filenames = ["dremel_example.parquet"]
batch_size = 1

exp = s2t.expression_impl.parquet.create_expression_from_parquet_file(filenames)
new_exp = exp.promote_and_broadcast({"new_field": "Links.Forward"}, "Name")
proj_exp = new_exp.project(["Name.new_field"])
proj_exp_needed = exp.project(["Name.Url"])
# Please note that currently, proj_exp_needed needs to be passed into calculate.
# This is due to the way data is stored in parquet (values and repetition &
# definition levels). To construct the node for "Name", we need to read the
# values of a column containing "Name".
pqds = s2t.expression_impl.parquet.calculate_parquet_values([proj_exp, proj_exp_needed], exp,
                                        filenames, batch_size)

for prensors in pqds:
  new_field_prensor = prensors[0]
  print("============================")
  print("Schema of new_field prensor: ")
  print(new_field_prensor)
  print("\nSparse tensor representation: ")
  pretty.pprint(new_field_prensor)
print("============================")
#@test {"skip": true}

from struct2tensor import expression_impl

filenames = ["dremel_example.parquet"]
batch_size = 1

exp = s2t.expression_impl.parquet.create_expression_from_parquet_file(filenames)
new_exp = exp.promote_and_broadcast({"new_field": "Links.Forward"}, "Name")
proj_exp = new_exp.project(["Name.new_field"])
proj_exp_needed = exp.project(["Name.Url"])
# Please note that currently, proj_exp_needed needs to be passed into calculate.
# This is due to the way data is stored in parquet (values and repetition &
# definition levels). To construct the node for "Name", we need to read the
# values of a column containing "Name".
pqds = s2t.expression_impl.parquet.calculate_parquet_values([proj_exp, proj_exp_needed], exp,
                                        filenames, batch_size)

for prensors in pqds:
  new_field_prensor = prensors[0]
  print("============================")
  print("Schema of new_field prensor: ")
  print(new_field_prensor)
  print("\nSparse tensor representation: ")
  pretty.pprint(new_field_prensor)
print("============================")

/usr/local/lib/python3.6/dist-packages/struct2tensor/expression_impl/parquet.py:65: FutureWarning: The 'field_by_name' method is deprecated, use 'field' instead
  [arrow_schema.field_by_name(name) for name in arrow_schema.names]))
/usr/local/lib/python3.6/dist-packages/struct2tensor/expression_impl/parquet.py:396: FutureWarning: The 'field_by_name' method is deprecated, use 'field' instead
  for step in curr_steps_as_set

============================
Schema of new_field prensor:
RootNodeTensor root
  repeated ChildNodeTensor Name
    repeated <dtype: 'int64'> new_field

Sparse tensor representation:
{Name.new_field: SparseTensor(values=[20, 40, 60, 20, 40, 60, 20, 40, 60], dense_shape=[1, 3, 3],
     indices=[[0, 0, 0], [0, 0, 1], [0, 0, 2], [0, 1, 0], [0, 1, 1], [0, 1, 2], [0, 2, 0], [0, 2, 1], [0, 2, 2]])}

============================
Schema of new_field prensor:
RootNodeTensor root
  repeated ChildNodeTensor Name
    repeated <dtype: 'int64'> new_field

Sparse tensor representation:
{Name.new_field: SparseTensor(values=[80], dense_shape=[1, 1, 1],
     indices=[[0, 0, 0]])}

============================

Your structured data into Tensorflow.¶

Demo example¶

Install required packages (internal colab users: skip)¶

Some Pretty Printing and Imports¶

The real work:¶

Lets see it in action:¶

Digging Far Deeper¶

Prensor¶

struct2tensor Query¶

Projection¶

Logical representation of a projection¶

Representing nested lists with tf.SparseTensor¶

Common struct2tensor Queries¶

promote¶

broadcast¶

promote_and_broadcast¶

map_field_values¶

reroot¶

Proto Map¶

Apache Parquet Support¶

Preparation¶

Prepare the input data¶

Example¶

Representing nested lists with `tf.SparseTensor`¶

`promote`¶

`broadcast`¶

`promote_and_broadcast`¶

`map_field_values`¶

`reroot`¶
